Linear
Steeler Line Recessed
Recessed linear continuous pendant luminaire complete with COB LED boards, opal/micro-prismatic diffuser and integral driver.
Colours
White (RAL 9003)
Black (RAL 9005)
Grey (RAL 7040)
Special RAL colours available on request
Light Source
COB LED module
CRI90; 2700, 3000, 3500 and 4000K
Diffusers
Prismatic
Micro-Prismatic
Opal
Materials
Housing made of aluminium, diffuser made from polycarbonate
Installation
Recessed, Single or Continuous
Driver
On/Off, DALI and Casambi
Max Power
88w
Max Lumens
9009
Measurements
Cut out: 587mm, 727mm, 867mm, 1007mm, 1147mm, 1287mm, 1427mm, 1707mm, 1987mm, 2127mm, 2267mm, 2547mm, 2967mm
Length: 597mm, 737mm, 877mm, 1017mm, 1157mm, 1297mm, 1437mm, 1717mm, 1797mm, 2137mm, 2277mm, 2557mm, 2977mm
54mm wide x 103mm high
